Linear Motion Solutions for Industrial Automation

Linear Motion Module Solutions & Precision Machining Support

Configure single-axis modules and multi-axis systems for industrial automation. HS LINEAR coordinates product selection, drawing review, production and quality follow-up through its supply chain in China, backed by local sales, technical support and after-sales service in Europe.

Multi-axis linear motion module system
Discuss your motion project
High Precision
Configurable Modules
Strict QC
Global Service
Linear Slide Rail

Why Choose Our Linear Motion Solutions

Configurable linear motion products and practical support for industrial automation equipment

Multiple Drive Options

Ball screw, belt-driven, rack and pinion, linear motor and electric actuator solutions for different motion requirements.

Configurable Product Options

Stroke, lead, motor position, sensor arrangement and accessories can be configured according to the application requirements.

Motor & Installation Flexibility

Multiple motor mounting, inline or foldback arrangements, different mounting directions and common mechanical interfaces.

Engineering Support

We assist with product selection and provide configuration and outline drawings for customer review before production.

Linear Module Configuration & Production Process

A clear process from requirement review and product selection to assembly, inspection and delivery.

01
Requirement ReviewUnderstand application needs
02
Product SelectionChoose the right module
03
Configuration & Drawing ApprovalConfirm specs & drawings
04
Production & AssemblyCoordinate production & assembly
05
Inspection & TestingQuality verification
06
Packing & DeliverySecure packing and shipment

Linear Motion Solutions

Single-axis modules and multi-axis configurations for industrial automation.

SINGLE-AXIS

Single-Axis Linear Modules

Six product families covering precision positioning, long-stroke transfer and actuator applications.

Ball Screw Linear Modules

1. Ball Screw Linear Modules

Ball-screw-driven modules for precise positioning, rigidity and repeatable motion.

  • Semi-Enclosed
  • Fully Enclosed
Belt-Driven Linear Modules

2. Belt-Driven Linear Modules

Belt-driven modules for long-stroke, high-speed and low-noise transfer.

  • Open Type
  • Semi-Enclosed
  • Fully Enclosed
Rack & Pinion Linear Modules

3. Rack & Pinion Linear Modules

Rack-and-pinion modules for long-stroke and heavy-load motion.

  • RP Series
  • Optional Dust Protection / Bellows
Linear Motor Modules

4. Linear Motor Modules

Direct-drive modules for high-speed, responsive and smooth motion.

  • LM Series
  • Direct Drive
Electric Linear Actuators

5. Electric Linear Actuators

Compact rod-type electric actuators for pushing, lifting and positioning.

  • AC Series
  • Rod-Type Actuator
Dual-Drive Linear Modules

6. Dual-Drive Linear Modules

Parallel-axis modules for wider loads and improved motion stability.

  • Belt-Driven Dual-Drive (BTDD)
  • Ball-Screw Dual-Drive (BSDD)
MULTI-AXIS

Multi-Axis Linear Motion Systems

Representative coordinated-motion configurations for multi-directional automation.

Cantilever Type

1. Cantilever Type

For vertical and horizontal motion.

  • C1 1-Axis Cantilever
  • C2 2-Axis Cantilever
Gantry Type

2. Gantry Type

For large-scale motion.

  • G1 2-Axis Gantry
  • G2 3-Axis Gantry
Polar Type

3. Polar Type

For rotational motion.

  • P1 2-Axis Polar
  • P2 3-Axis Polar
Linkage Type

4. Linkage Type

For complex motion paths.

  • L1 2-Axis Linkage
  • L2 3-Axis Linkage

Custom CNC Machined Parts

Custom machined components for automation equipment and industrial machinery

Linear Motion Integration & Precision Machining Support

Share your load, stroke, speed and installation requirements. We can suggest a practical module direction and coordinate any supporting machined parts.

Discuss Your Application
